The NIBCO® lead-free* ball valve with drain features solder ends for easy installation. The valve is constructed of lead-free dezincification-resistant (DZR) high quality performance bronze silicon alloy per ASTM specifications. The two-piece valve is recommended for applications that deliver water for human consumption, including commercial and residential construction.
NIBCO Ball Valve Lead-Free Two-Piece Full Port with Drain-FIG NO-S-685-80-D-LF
- Valve pressure rating 600 psi/41.4 bar non-shock cold working pressure
- Full port
- Silicon Performance Bronze® ball and stem
- Blowout-proof stem
- PTFE seats
- White handle for easy lead-free identification
- NIBCO® double-oval lead-free body marking
- Solder end connections
- Dezincification resistant
- Lead-free
- Conforms to MSS SP-110
- NSF/ANSI/CAN-61 and 372
Description
Reviews (0)
Shipping & Delivery
Related products
WEFLO Pressure Relief Valve FL x Gr Ends FIG.F1319
Specifications:
Relief Valve: Limits inlet pressure by relieving excess pressure. Pressure sustaining: Prevents pipe line pressure from rising to a maximum valve.
Operates over a Wide Flow Range.
*Inlet Pressure Adjustment Range:65-300psi.
Quick opening and adjustable closing speed. Flanged to EN 1092-2 PN16,ANSlClass125/150/250.(Other available on request)
e Grooved Ends to AWWA C606 Standard.
*Rated Working Pressure 300 psi.
UL 1478 Listed and FM 1361 Approved.
WEFLO Adjustable Relief Valve FIG.F1329
General Description
F1329 bronze adjustable relief valve is rated for up to 310 psi. The adjustable relief valve allows for the required NFPA field hydrostatic testing to be accomplished without removing and/or plugging the outlet for the relief valve. Note: Visual calibration lines on valve are used for approximate adjustment, must verify pressure setting with pressure gauge.
WEFLO Pressure Reducing Valve FIG.F1321-300
Specifications
Multiple End Types for Main Valve:
Flange by Flange, Flange by Groove, Groove by Groove. Pressure Relief Valve:
Limits pipe line pressure by release excess pressure.
Pressure sustaining: Prevents pipe line pressure from rising to a maximum value.
Operates over a wide flow range.*Inlet pressure adjustment range: 65~180psi.Can be maintained without removal from the pipe line.
Flanged to EN1092-2 PN10/PN16,ANSI B16.1 Class125(Other available on request)
Grooved ends to AWWA C606 Standard.
Rated Working Pressure: 300 psi.
Adjustment Range of Set Pressure: 65 to 180 psi.Fusion Bonded Epoxy Coated Interior and Exterior to AWWAC550 Standard.FM 1361 Approved.CNBOP Certified.
WEFLO Pressure Relief Valve Gr x Gr Ends FIG.F1319
Specifications
Relief Valve: Limits inlet pressure by relieving excess pressure.
Pressure sustaining: Prevents pipe line pressure from rising to a maximum valve.
Operates over a Wide Flow Range.
*Inlet Pressure Adjustment Range: 65-300psi.
Quick opening and adjustable closing speed.
*Grooved Ends to AWWA C606 Standard.
Rated Working Pressure 300 psi.
UL 1478 Listed and FM 1361 Approved.
WEFLO C515 NRS Resilient Seated Gate Valve 14“-24” FIG.F1211-300
Specifications :
Multiple End TypesF1211-300:Flange by FlangeF0213-300:Flange by MJF0233-300:MJ by MJ
Meet or exceed the requirements of AWWA C515 Standard.
Full Waterway.
Triple O-Ring Stem Seal.
Ductile-Iron Wedge, EPDM Encapsulated.
Operated with handwheel or operating nut.
Flanged to ASME B16.1 Class 125.
Other Flange Types available upon request. Mechanical Joint Outlets comply withANSIAWWAC153/A21.53Rated Working Pressure: 300 psi.
UL/ULC Listed and FM Approved.
WEFLO Pressure Relief Valve FL x FL FIG.F1349
Specifications:
- Relief Valve: Limits inlet pressure by relieving excess pressure.
- Pressure sustaining: Prevents pipe line pressure from rising toa maximum valve.
- Operates over a Wide Flow Range.
- Inlet Pressure Adjustment Range:65~300psi.
- Quick opening and adjustable closing speed.
- Flanged to EN1092-3 PN16,ANS| Class150/300.(Other available on request)
- Rated Working Pressure 300 psi.
- UL1478 Listed and FM 1361Approved.
WEFLO Swing Check Valve, Flanged Ends FIG.F1322
Specifications
Meet or exceed the requirements of AWWA C508 Standard.
Full Waterway.
Disc is fully encapsulated with EPDM rubber.
Superior design featuring exceptionally low pressure losses at high flow rates.
Disassembly of the valve can be performed without removing the valve from the pipe system by unscrewing the bonnet bolts. Face to face dimensions according to ASME B16.10.Flanged to ASME B16.1 Class 125,EN 1092-2 PN16.Other flange types are available on request. Rated Working Pressure: 350 psi. UL/ULC Listed and FM Approved.
ANSI/NSF61&372 Certified.
WEFLO C515 OS& amp Y Resilient Seated Gate Valve 14“-24” FIG.F1111-300
Specifications :
Multiple End Types
F1111-300:Flange by FlangeF0113-300:Flange by MJF0133-300:MJby MJ
Meet or exceed the requirements ofAWWAC515 Standard.
Full Waterway.
Adjustable Packing.
Ductile-Iron Wedge, EPDM Encapsulated.
Flanged to ASME B16.1 Class 125.OtherFlangeTypes available upon request. Mechanical Joint Outlets comply with ANSI/AWWAC153/A21.53Rated Working Pressure: 300 psi. UL/ULC Listed and FM Approved,
